2 series round aluminum bars

Series 2 Aluminum: 2A12, 2017, 2024, 2A11, 2117
Features: It can be strengthened by heat treatment, has medium plasticity in annealing, just quenching and hot state, has good spot welding properties, and has a tendency to form intergranular cracks when using gas welding and argon arc welding, etc.
Applications: aircraft structures (skin, frame, rib beam, bulkhead, etc.), aircraft, ships, transportation, rivets, missile components, truck wheels, propeller components, etc.

Fields marked with * must be filled in. Please fill in your commonly used email address or WhatsApp phone number for us to contact you. We value privacy and will not disclose any of your information to any third party.

Product Details

Aluminum Chemical Composition
Grades	Cu	Si	Fe	Mn	Mg	Zn	Cr	Pb	Bi	Al
2011	5.0-6.0	≤0.4	≤0.7	≤0.05	≤0.05	≤0.3	≤0.05	0.2-0.6	0.2-0.6	Remainder
2017	3.5-4.5	0.2-0.8	≤0.7	0.4-1.0	0.4-0.8	≤0.25	≤0.1	≤0.15	/	Remainder
2014	3.9-5.0	0.50-1.2	≤0.7	0.4-1.2	0.2-0.8	≤0.25	≤0.1	≤0.15	/	Remainder
2024	3.8-4.9	≤0.5	≤0.5	0.3-0.9	1.2-1.8	≤0.25	≤0.1	≤0.15	/	Remainder
Aluminum Bar Mechanical Properties
Grades	RmMPa		Rp0,2MPa			A50 mm% min.			HBW Typischer Wert
2011	≥280		≥210			≥8%			≥90
2017	≥340		≥220			≥6%			≥95
2014	≥380		≥290			≥6%			≥110
2024	≥425		≥290			≥7%			≥120
Aluminum Tube Mechanical Properties
Grades	RmMPa		Rp0,2MPa			A50 mm% min.			HBW Typischer Wert
2011	≥290		≥240			≥6%			≥90
2017	≥370		≥250			≥5%			≥95
2014	≥380		≥290			≥6%			≥110
2024	≥420		≥270			≥8%			≥120
Spot Regular Status
O、H111、T3、T351、T3510/T3511、T4、T42、T451、T4510/T4511、T6、T651、T6510/T6511、T8、T851
Spot Routine Implementation Standards
Aluminium and aluminium alloy extruded rods/bars,tubes and profles Chemicalcomposition+Mechanical properties：ASTM B221
Wrought Aluminium and aluminium alloyextruded profles Chemical composition+Mechanical properties:JIS H4100-2006
Wrought Aluminium and aluminium alloy extruded rods/bars Chemical composition+Mechanical properties:JIS H4040-2006
Aluminium and aluminium alloy extruded rods/bars Chemical composition：GB/T3190-2008
Aluminium and aluminium alloy extruded rods/bars Mechanical properties：GB/T3191-2010
