2017 aluminum rods, aluminum tubes, aluminum profiles

2017 aluminum rods, aluminum tubes, aluminum profiles - Image 2

2017 aluminum rods, aluminum tubes, aluminum profiles

Zhenhan supplies 2017 aluminum bar, supports bulk purchase, and can be customized according to customer needs.

Fields marked with * must be filled in. Please fill in your commonly used email address or WhatsApp phone number for us to contact you. We value privacy and will not disclose any of your information to any third party.

Product Details

2017Aluminum Alloy Chemical Composition
Cu	Si	Fe	Mn	Mg	Zn	Cr	Ti	Pb+Bi	Al
3.5-4.5	0.2-0.8	≤0.7	0.4-1.0	0.4-0.8	≤0.25	≤0.1	≤0.15	/	Remainder

2017Aluminum Rod Mechanical Properties
Werkstoff-zustand	Rm MPa	Rp0,2 MPa	A50 mm % min.	HBW Typischer Wert
O	≤245	≤125	≥16%	/
T3	≥340	≥220	≥6%	≥95
T351	≥370	≥240	≥3%	≥95
T4	≥345	≥215	≥12%	/
T42	≥335	≥195	≥12%	/

2017Aluminum Tube Mechanical Properties
Werkstoff-zustand	Rm MPa	Rp0,2 MPa	A50 mm % min.	HBW Typischer Wert
T3	≥370	≥250	≥5%	≥95
T3510/T3511	≥370	≥240	≥3%	≥95
Aluminium and aluminium alloys – Chemical compositionand form of wrought productsPart 3: Chemical compositionEnglish version of DIN EN 573-3
Aluminium and aluminium alloys-Cold drawn rod/bar and tube Part 2 Mechanical properties:DIN EN 754-2-2008
Aluminium and aluminium alloys-Extruded rod/bar,tube and profiles Part 2:Mechanical properties: DIN EN_755-2-2008
Aluminium and aluminium alloyextruded rods/bars, round bars Chemical composition+Mechanical properties: ASTM B21M-20o1
Aluminium and aluminium alloy extruded rods/bars,tubes and profles Chemicalcomposition+ Mechanical properties: ASTM B221
Wrought Aluminium and aluminium alloyextruded profles Chemical composition+ Mechanical properties:JIS H41o0-20o6
Wrought Aluminiumn and aluminium alloy extruded rods/bars Chemical composition+ Mechanical properties:JIS H4040-2006
Aluminium and aluminium alloy extruded rods/bars Chemical composition: GB/T3190-20o8
Aluminium and aluminium alloy extruded rods/bars Mechanical properties: GB/T3191-201o

2017Applications of Aluminum Materials
This alloy grade offers excellent machinability, high strength, and high hardness, along with a certain degree of heat resistance. Applications include rivets, general mechanical parts, aircraft and missile structures, and other structural components requiring high strength.
