5052 aluminum rectangular tube

Zhenhan supplies high-quality 5052 aluminum rectangular tube, supports large-volume purchases, and offers flexible customization to meet your diverse needs. With reliable quality and fast delivery, we are your ideal aluminum partner!

Fields marked with * must be filled in. Please fill in your commonly used email address or WhatsApp phone number for us to contact you. We value privacy and will not disclose any of your information to any third party.

Product Details

5052Aluminum Alloy Chemical Composition
Cu	Si	Fe	Mn	Mg	Zn	Cr	Ti	Pb+Bi	Al
≤0.1	≤0.25	≤0.4	≤0.1	2.2-2.8	≤0.1	0.15-0.35	≤0.05	/	Remainder
5052Aluminum Rod Mechanical Properties
Werkstoff-zustand	Rm/MPa			Rp0,2/MPa			A50 mm/% /min.			HBW/Typischer Wert
O/H111	170-230			≥65			≥17%			≥45
F/H112	≥170			≥70			≥15%			≥47
H12/H22/H32	210-250			≥160			≥5%			≥60
H14/H24/H34	230-270			≥180			≥4%			≥68
H16/H26/H36	250-290			≥200			≥3%			≥73
H18/H28/H38	≥270			≥220			≥2%			≥77
5052Aluminum Tube Mechanical Properties
Werkstoff-zustand	Rm/MPa			Rp0,2/MPa			A50 mm/% /min.			HBW/Typischer Wert
O/H111	170-230			≥65			≥17%			≥47
H14/H24/H34	230-270			≥180			≥4%			≥68
H18/H28/H38	≥270			≥220			≥2%			≥77
Aluminium and aluminium alloys – Chemical compositionand form of wrought productsPart 3: Chemical compositionEnglish version of DIN EN 573-3
Aluminium and aluminium alloys-Cold drawn rod/bar and tube Part 2 Mechanical properties:DIN EN 754-2-2008
Aluminium and aluminium alloys-Extruded rod/bar,tube and profiles Part 2:Mechanical properties:DIN EN_755-2-2008
Aluminium and aluminium alloyextruded rods/bars, round bars Chemical composition+Mechanical properties：ASTM B211M-2001
Aluminium and aluminium alloy extruded rods/bars,tubes and profles Chemicalcomposition+Mechanical properties：ASTM B221
Wrought Aluminium and aluminium alloyextruded profles Chemical composition+Mechanical properties:JIS H4100-2006
Wrought Aluminium and aluminium alloy extruded rods/bars Chemical composition+Mechanical properties:JIS H4040-2006
Aluminium and aluminium alloy extruded rods/bars Chemical composition：GB/T3190-2008
Aluminium and aluminium alloy extruded rods/bars Mechanical properties：GB/T3191-2010
5052Applications of Aluminum Materials
This series boasts advantages such as corrosion resistance, weldability, surface treatment properties, good plasticity, and low density; it is widely used in optical instruments, rivets, semiconductors, optical lenses, applications requiring high corrosion resistance and machinability, welded structures, forged parts, and load-bearing components for welded containers, among other fields.
